Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds

MOQ: 1 unit
Price: Negotiable
Standard Packaging: Wooden Case Packing
Delivery Period: 15-30days
Payment Method: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Capacity: 1000 unit/month
Details Information
Product Description
Detail Information
Place of Origin
Foshan City ,China
Brand Name
Olang
Certification
ISO
Model Number
OL-119
Series:
DIGI TIG 400/500 ACDC PULS
Condition:
New
Pulse Frequency:
50-60Hz
Rated Voltage:
380V
Output Amps:
160A
Arcing:
High Frequency
Highlight:

Gas Flow Control TIG Welding Machine

,

Quick Setup TIG Welding Machine

,

Strong Welds TIG Welding Machine

Product Description

Quick Setup Gas Flow Control TIG Welding Machine for Strong Welds



  • 1. Precise and High-Quality Welding

  • Produces clean, high-quality welds with minimal spatter.

  • Ideal for thin materials and applications requiring fine weld aesthetics.

  • Provides deep penetration and strong welds, ensuring durability.

  • 2. Portable and Flexible Operation

  • Compact and lightweight design, easy to carry and operate in tight spaces.

  • Suitable for on-site welding, repair work, and maintenance tasks.

  • 3. Versatile Material Compatibility

  • Works with a wide range of metals, including stainless steel, aluminum, titanium, copper, and carbon steel.

  • Supports welding of both thin and thick materials with precise heat control.

  • 4. Stable Arc and Heat Control

  • Delivers a stable arc with adjustable current settings for different welding needs.

  • Enables smooth and consistent weld beads with minimal distortion.



TECHNICALPARAMETER



M o d e l TIG-250T TIG-300T WSM-400F WSM-500F



Supply voltage(V)



 Single-phase 220V±10% Three-phase 220V/380V±10%

Three-phase

380V±10%

Three-phase

380V±10%



Rated frequency(Hz) )

 50/60Hz 50/60Hz 50/60Hz 50/60Hz



Rated supply energy(KVA)(KVA)

 8.6 4.5 18 24



Maximum load voltage(V)

 60 71 72 76



Rated load sustained rate(%)

 60% 60% 60% 60%



Rated output current(A)

 10-160 10-240 10-400 10-500



Rated pulse current(A)

     400 500



Base current(A)

     10-400 10-500



Impulse frequency(Hz)

     0.1-99.9 0.1-99.9



Thrust current(A)

     20-150 20-150

Exterior dimension(mm) Weight(Kg







 410*175*335 7.9





440*205*355 10.5

Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds 0







510*252*456 21.5

Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds 1





530*300*532 28.2













Application



  • Aerospace and Shipbuilding Industry: Degreasing, degreasing and cleaning, paint removal, rust removal.

  • Automobile Manufacturing: Degreasing, cleaning of tire molds, removing coatings from galvanized sheets before welding.

  • Electronics and Semiconductor Industry: Cleaning of silicon wafers.

  • Marine, Railway, and Bridge Industry: Rust removal, paint removal.

  • Chemical, Food, and Medical Industries: Cleaning small holes in thin metal filter plates.

  • Building Cleaning: General cleaning of buildings.

  • Nuclear Power Plant Reactor Pipe Cleaning: Cleaning of pipes inside nuclear reactor systems.

Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds 2

Factory work shop
Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds 3



Package:
Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds 4

Exhibiton:
Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds 5

Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds 6

Certificate
Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds 7
Quick Setup Gas Flow Control TIG Welding Machine For Strong Welds 8
